    Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

    Ask Lasest Price
    Supply Ability : 50000pecises/Year
    Certification : ISO9001
    Price : 10-1000
    Delivery Time : 15 days
    Payment Terms : TT,western
    • Product Details
    • Company Profile

    Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

    12V190 Sand Pump Vessel Engine Parts


    Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
    Main business scope:
    Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
    Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
    Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.

    12V190 Sand Pump Vessel Engine Parts

    Series 2000V marine diesel engines
    ModelRated Power(kw/hp)Rated speed(r/min)Specific fuel consumption(g/kw'h)Specific oil consumption(g/kw'h)Overall dimension L*B*H(mm)Net weight(kg)
    Z12V190BC1800/10801500≤209.4≤1.62642*1588*20705300
    Z12V190BC2882/12001500≤209.4≤1.62642*1588*20705300
    Z12V190BC81000/13601500≤209.4≤1.62642*1588*20705300
    Z12V190BC9882/12001500≤209.4≤1.62642*1588*20705300
    Z12V190BC10900/12251450≤209.4≤1.62642*1588*20705300
    Z12V190BC11882/12001500≤209.4≤1.62642*1588*20705300
    G12V190ZLC11000/13601450≤209.4≤1.62642*1588*20705300
    G12V190ZLC21000/13601450≤209.4≤1.62642*1588*20705300
    Main technical data
    No. and arrangement of cylinders:12,60
    .Vee
    Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
    Bore:190mm
    Stroke:210mm
    Total displacement:71.45L
    Compression ration:14:1
    Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
    Starting method:Air motor or electric motor
    Lubricating method:Pressure and splash lubrication
    Model of generating setModel of diesel enginesModel of generatorRated Power KWRated voltage VRated frequency HZOverall dimension L*B*H(mm)Net weight KG
    CCFJ400/1000Z12V190BCD-2TFC5454-6JH42400390504210*1500*226010500
    CCFJ630/1500Z12V190BCDTFC5456-4JH42630390504260*1500*226012000
