    Certified ISO9001 Push Diesel Engine G12V190pzl for Drilling in Oil Field at 1300r/Min

    Ask Lasest Price
    Supply Ability : 50000pecises/Year
    Certification : ISO9001
    Price : 10-1000
    Delivery Time : 15 days
    Payment Terms : TT,western
    • Product Details
    • Company Profile

    Certified ISO9001 Push Diesel Engine G12V190pzl for Drilling in Oil Field at 1300r/Min

    Diesel Engine Used in Oil Field for Drilling 1300r/Min G12V190pzl
    ModelRated Power(KW/hp)Rated Speed(r/min)Specific fuel consumption(g/kw.h)Specific oil consumption(g/kw.h)Overall Dimension L*B*H(mm)Net weigh(KG)
    BG12V190ZL900/1500800/1500≤209.4≤1.63160*1770*24005300
    BG12V190PZL900/1500800/1500≤209.4≤1.64374*1740*24008100
    BG12V190ZL-3810/1300730/1300≤209.4≤1.63160*1770*24005300
    BG12V190PZL-3810/1300730/1300≤209.4≤1.64374*1740*24008100
    G12V190ZL900/1500800/1500≤209.4≤1.62692*1560*20705300
    G12V190PZL900/1500800/1500≤209.4≤1.63860*2040*26788100
    G12V190ZL-3810/1300730/1300≤209.4≤1.62692*1560*20705300
    G12V190PZL-3810/1300730/1300≤209.4≤1.63860*2040*26788100
    G12V190ZL-1740/1200660/1200≤209.4≤1.62692*1560*20705300
    G12V190PZL-1740/1200660/1200≤209.4≤1.63860*2040*26788100
    G12V190ZL-2600/1000540/1000≤209.4≤1.62692*1560*20705300
    G12V190PZL-2600/1000540/1000≤209.4≤1.63860*2040*26788100
    G8V190ZL600/1500540/1500≤213.5≤2.71802*1560*20704300
    G8V190PZL600/1500540/1500≤213.5≤2.73280*2040*26786750
    G8V190ZL-3510/1300460/1300≤213.5≤2.71802*1560*20704300
    G8V190PZL-3510/1300460/1300≤213.5≤2.73280*2040*26786750
    G8V190ZL-1470/1200425/1200≤213.5≤2.71802*1560*20704300
    G8V190PZL-1470/1200425/1200≤213.5≤2.73280*2040*26786750
    G8V190ZL-2390/1000350/1000≤213.5≤2.71802*1560*20704300
    G8V190PZL-2390/1000350/1000≤213.5≤2.73280*2040*26786750
    Main technical data
    No. and arrangement of cylinders:12,60.Vee
    Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
    Bore:190mm
    Stroke:210mm
    Total displacement:71.45(47.6)L
    Compression ration:14:1
    Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
    Starting method:Air motor or electric motor
    Lubricating method:Pressure and splash lubrication
    Diesel Engine Used in Oil Field for Drilling 1300r/Min G12V190pzl
    Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
    Main business scope:
    Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
    Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
    Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
    Later stage:Overhaul and maintenance service offered.
